What is a Siphon Tube? A siphon tube in short is a protecting tool for a pressure sensor. It protects the pressure sensors from unwanted hot temperature agents such as stem etc. Moreover, it also safeguards the pressure sensor from unwanted rapid pressure changes. These rapid changes can damage the pressure sensing mechanism working with spring. Siphon tubes are a cheap solution to increase the life of pressure sensors. Saving them from high temperatures. Types of Siphon Tube? Siphon pipes can be differentiated on the basis of their material and their shape. Most commonly stainless steel siphon tubes are used. They come in variety of grades such as stainless 202, 304 and 316 grades. One can find these tubes also in WCB material and carbon steel forging material. Boilers are required to have a pressure meter with an IBR certified syphon tube. Siphon tubes can also made in other alloy materials. Siphon tubes are also fabricated in different shapes. Most common are Q type and U type. These come in either threaded ends or butt welded ends for carbon steel material. These tubes can be fitted with additional coils for longer ends. User decides upon the design of the tube as per the space available. You can check SS 304 Siphon Tube U type here. FAQs for SS 304 Siphon Tube Q Type (Pigtail) 1/2″ / 3/8″: 1. What is an SS 304 Siphon Tube Q Type (Pigtail) used for?An SS 304 siphon tube Q Type is used to protect pressure gauges and sensors from high-temperature steam by reducing heat transfer and ensuring accurate pressure readings. 2. How does a siphon tube improve pressure gauge life?A siphon tube traps condensate inside the coil, creating a cooling barrier that prevents direct exposure of hot steam to the gauge, thereby extending its operational life. 3. Is the SS 304 siphon tube suitable for steam and high-pressure applications?Yes, the SS 304 siphon tube is corrosion-resistant, heat-resistant, and ideal for steam lines, boilers, and high-pressure industrial applications. 4. What is the advantage of using a Q Type (Pigtail) design in a siphon tube?The Q Type (Pigtail) design in a siphon tube provides efficient condensate collection and consistent cooling, ensuring accurate pressure measurement and improved gauge durability. SKU: 92a8ba631e40 Categories: Gauge Accessories, Gauges & accessories Tags: gauge tube, pigtail, pressure gauge pipe, pressure gauge tube, q type, ss syphon tube, stainless steel syphon tube, syphon tube, syphon tube pressure gauge
