AP 550 Label Applicator

Description 200311_Compressed_AllLabelBrochure_Web Features: Easy to use Full range of motion Left or right justification of labels is not necessary; the operator can adjust to the most convenient position High-precision, reliable micro-switch activatione Nothing to clean or get dirty; works with virtually any label, including clear labels LED display with built-in up/down counter for labels dispensed and applied Universal Power Supply Specification: Container Platform  12” W x 12.2” D [305 x 310 mm] * Container Height  .002” to 8” [.05 mm to 203 mm] ** Container Shape  Flat, tapered Label Width  .75” to 4” [19 mm to 101.6 mm] Label Height  .75” to 6” [19 mm to 152.4 mm] Label Liner Width  .875” to 4.125” [22.2 mm to 104.8 mm] Label Placement  Leading edge up to 8” [203 mm] from trailing container edge Label Roll Diameter  8” [203 mm] (maximum) Label Roll Core  2” to 3” ID [50.8 mm to 76.2 mm] Sensor Type Optical Sensor Electrical Rating  12 VDC, 5.0 A Power Requirements  100-240 VAC, 50/60 Hz, 60 watts Agency Certifications  UL, UL-C, CE, FCC Class A California Prop 65: WARNING: Cancer and Reproductive Toxin – www.p65warnings.ca.gov Weight  24 lbs [10.9 kg] Dimensions  12” W x 21.3” D x 10.1”–15.4” H [305 x 541 x 256–391 mm] Gap between Labels: Recommended: 1/8″ – 1/4″ ( 3.175 mm – 6.3500 mm ) Label Type: Die cut with waste removed. Black mark or gap for label sensor. Clear labels must have black mark on liner. (Labels digitally die-cut on the LX610 are not compatible because the waste is not removed. Learn More.) Liner Thickness: 2 mil – 10mil (smoothness will affect feeding – a liner that is too slippery or too thin will slip through the drive rollers) Label Adhesive Thickness: 5 mil – 15 mil*** Wind Direction Wound out – See Copy-Position Chart (Position 3 or 4 for most containers) Assembled  USA * Container may overhang platform to the front and/or either side. ** Containers shorter than .8” (20.3 mm) may require adaptive spacers. ***Pliability/Flexibility/Rigidity of the label is also a factor. If the label is too flexible, no matter the thickness, it can cause wrinkling or it may not pop off the liner when going around the peel edge. Polypropylene, Polyester and Vinyl labels tend to be more flexible that paper labels. If you suspect the label stock is too flexible, it is recommended that the stock and container be tested on the Applicator before making any purchase decisions of label stock or the applicator.
